Auto Flip Flop Stacker Machine designed to improve corrugated cardboard production by automating paper counting turning and stacking processes

Auto Flip Flop Stacker Machine designed to improve corrugated cardboard production by automating paper counting turning and stacking processes
Auto Flip Flop Stacker Machine designed to improve corrugated cardboard production by automating paper counting turning and stacking processes
Auto Flip Flop Stacker Machine designed to improve corrugated cardboard production by automating paper counting turning and stacking processes Auto Flip Flop Stacker Machine designed to improve corrugated cardboard production by automating paper counting turning and stacking processes Auto Flip Flop Stacker Machine designed to improve corrugated cardboard production by automating paper counting turning and stacking processes Auto Flip Flop Stacker Machine designed to improve corrugated cardboard production by automating paper counting turning and stacking processes Auto Flip Flop Stacker Machine designed to improve corrugated cardboard production by automating paper counting turning and stacking processes Auto Flip Flop Stacker Machine designed to improve corrugated cardboard production by automating paper counting turning and stacking processes Auto Flip Flop Stacker Machine designed to improve corrugated cardboard production by automating paper counting turning and stacking processes

Ampliación de imagen :  Auto Flip Flop Stacker Machine designed to improve corrugated cardboard production by automating paper counting turning and stacking processes

Datos del producto:
Lugar de origen: Anhui
Nombre de la marca: Innovo Bochen
Certificación: CE
Número de modelo: ZST-1450/1650/1900/2200
Pago y Envío Términos:
Cantidad de orden mínima: 1 juego
Precio: 24000-40000USD
Detalles de empaquetado: Bolsa de vacío
Tiempo de entrega: 15-30 días
Capacidad de la fuente: 50 juegos por mes
Contacto

Auto Flip Flop Stacker Machine designed to improve corrugated cardboard production by automating paper counting turning and stacking processes

descripción
Uso: apilado de paletas para papel laminado Ajuste de tamaño: Por pantalla táctil una tecla
Punto de venta: Ahorre el trabajo Velocidad de apilamiento: FLAUTA E 12000 piezas/hora
Tipo de máquina: Apilamiento de paletas para tablero Uso de la máquina: Apilamiento de papel después de la laminación
Pesaje de la red de la máquina: 4800 kg Tamaño de la hoja mínima: 42*45 cm
Velocidad de apilamiento: 12000pcs/hora (flauta E) Tamaño máximo del tablero: 1450*1450 mm
Resaltar:

auto flip flop stacker machine

,

corrugated cardboard stacker machine

,

automated paper counting stacker

Auto Flip Flop Stacker Machine designed to improve corrugated cardboard production by automating paper counting turning and stacking processes
Auto Flip Flop Stacker Machine For Flute Litho Laminator

This stacking machine is an essential accessory for flute laminating machines, designed to automate paper counting, turning, and stacking processes in corrugated cardboard production.

Machine Details

The system consists of four integrated components:

  • Slow paper table for controlled material feed
  • Stacking table for paper accumulation
  • Turning table with paper pile inversion mechanism
  • Paper receiving table with pallet system

The automated process significantly reduces labor requirements while improving delivery efficiency and reducing manual handling intensity.

Technical Specifications
Model ZST-1450 ZST-1650
Max size 1500×1500mm 1700×1700mm
Min size 420×450mm 420×450mm
Applicable paper 150-800g/m² 150-800g/m²
Bottom paper A-F corrugated board, ≤10mm A-F corrugated board, ≤10mm
Speed 12,000 pcs/hour 12,000 pcs/hour
Power 8 kW 10 kW
Key Features
  • Newly designed delivery bin eliminates paper indentation from metal contact
  • Advanced belt conveying mechanism prevents creasing from paper weight
  • Fully automated paper counting and stacking process
  • Precision paper turning mechanism for consistent results
Machine Components
Auto Flip Flop Stacker Machine designed to improve corrugated cardboard production by automating paper counting turning and stacking processes 0
Optional Features
Auto Flip Flop Stacker Machine designed to improve corrugated cardboard production by automating paper counting turning and stacking processes 1

Semi-automatic pallet loading option available, providing labor savings and enhanced operator safety.

Machine Overview
Auto Flip Flop Stacker Machine designed to improve corrugated cardboard production by automating paper counting turning and stacking processes 2
